Hose is suitable for use as a connector over 1″ Schedule 40 pipe.
Nominal Hose inner diameter (ID) is 1.25″
Hose outer diameter (OD) is 1.75″
Standard connector length is 4.5″.
Temperature Range: -65˚F to 350˚F
Operating Pressure: 65 psi
Burst Pressure: 275 psi
Weight: .47 lbs per foot
Specially coated silicone elastomer with woven polyester fabric vulcanized and post cured. Meets SAE J20R1 Class Standard wall. The hose is blue in color.
Hose clamps are stainless steel, worm gear type, HS-36.
1″ Flex Hose with clamps
3-Ply Silicone Coolant Hose
Operating Pressure: 65psi
Burst Pressure: 275psi
Weight: 0.47lb /ft
|Shipping Weight:||0.25 lbs|
|Shipping Dimensions:||2 × 2 × 4 in|
