Product Description

CP 4007 Blower from MD Pneumatics / Tuthill

The 4007 CP Positive Displacement Blower is a model from Tuthill’s M-D Pneumatics division.

These units are designed to be interchangeable with equivalent Roots™ URAI models.  pdblowers is the largest distributor for Howden Roots, the top manufacturer of positive displacement blowers, and we keep many Roots URAI blowers in stock and ready to ship.  We also offer repair services for the Tuthill Competitor blowers. Click here to learn more about Tuthill 4007 blower repair.

The Roots equivalent for a 4007 blower is the Roots 47 URAI, although it is always recommended to check your specific performance requirements when selecting a blower. A basic comparison of specs is below; for more information or to buy online, click here for the Roots 47 URAI blower. Please note the 4007 CP blower is available with 2 lobes or 3 lobes; the specs shown below apply to the 2 lobe unit.

Tuthill 4007 vs Roots 47 URAI

CP 4007 URAI 47
Flow Range: to 492 CFM to 523 CFM
Max Δ Pressure: 7 psi 7 psi
Max Δ Vacuum: 16″ Hg 15″ Hg
Maximum RPM: 3600 3600
Minimum RPM: 850 848
Max ΔT: 170˚F 225˚F
Connection: 3″ NPT 3″ NPT
Shaft Dia.: 0.875″ 0.875″
Drive End Lubrication: Grease Grease
Gear End Lubrication: Oil Oil
Required Oil for Horizontal Unit: 8.5 ounces 22.8 ounces
Required Oil for Vertical Unit: 5.8 ounces 12.7 ounces
Unit Weight: 138 lb 128 lb



Tuthill Model Numbers

Model numbers consist of 13-15 characters and will be stamped on a nameplate attached to the blower, along with the unique serial and year of manufacture.  The first four characters of the model number indicate gear diameter and rotor length. The remainder of the characters indicate other blower configuration options including the types of lubrication and seals, lobes, drive location, blower materials, etc.  An example part number is 4007-A6L2CV1.  Please note older part numbers had a different structure: example 4007-21L2.
